Application Tag Commands
102 Command Set
Examples
The following example will attempt to write to Reserved Memory to set the Kill
password=0x11112222. It will write this data to a tag matching the following criteria for a
max timeout of 1000 ms.
Memory Bank = User Memory.
Starting Address = bit 32
Select Data = 0x1234
The Reserved Memory bank is not locked so the Access Password is zero
If Option=0x00 or 0x01 is used then the unused Tag Singulation Fields must be removed
from the request.
Note
If Option=00, the write tag data is performed without any select criteria
resulting the first tag found being written. In that case there is no way to
determine what tag gets written to unless there is only one tag in the RF
field.
The next example will attempt to write 4 words to User Memory starting at the second
word. It will write this data to a tag matching the following criteria for a max timeout of
1000 ms.
EPC ID= 0x0123456789ABCDEF01234567
The User Memory bank is not locked so the Access Password is zero
FF 17 24 03 E8 03 00 00 00 00 00 00 00 00 00 00 00 00 20 10 12 34
SOH Lengt
h
OpCode Time-
out (ms)
Option Write Address Write
MemBank
Access Password Select Address Select
Data
Length
Select
Data
11 11 22 22 3E 71
Write Data CRC
FF 21 24 03 E8 01 00 00 00 02 03 00 00 00 00 60
SOH Lengt
h
OpCode Time-
out (ms)
Option Write Address Write
MemBank
Access Password Select
Data
Length
