Set Application Commands
152 Command Set
Set Application Commands
The Set commands are used to set configurable values in the firmware. Since the values
are not stored in flash, these values are reset to the default values whenever the
application firmware is restarted. The application responds with a fault code / ACK to all
commands.
The following table lists the Application Set commands:
Set Application Commands
Error Status Codes
FAULT_MSG_WRONG_NUMBER_OF_DATA – 100h
FAULT_MSG_INVALID_PARAMETER_VALUE - 105h
OpCode Command Name Bootloader App Firmware
0x91 Set Antenna Port (91h) N Y
0x92 Set Read TX Power (92h) N Y
0x93 Set Current Tag Protocol (93h) N Y
0x94 Set Write TX Power (94h) N Y
0x95 Set Frequency Hop Table (95h) N Y
0x96 Set User GPIO Outputs (96h) N Y
0x97 Set Current Region (97h) N Y
0x98 Set Power Mode (98h) N Y
0x99 Set User Mode (99h) N Y
0x9A Set Reader Configuration(9Ah) N Y
0x9B Set Protocol Configuration (9Bh) N Y
