Application Tag Commands
Command Set 103
Note: Try reading back the value written in this example with the Read Tag Data Examples
showing reading from the same tag.
Error Status Codes
FAULT_MSG_WRONG_NUMBER_OF_DATA – 100h
FAULT_MSG_INVALID_PARAMETER_VALUE - 105h
FAULT_NO_PROTOCOL_DEFINED – 401h
FAULT_AFE_NOT_ON – 405h
FAULT_NO_TAGS_FOUND – 400h
FAULT_PROTOCOL_WRITE_FAILED – 406h
FAULT_PROTOCOL_INVALID_ADDRESS – 409h
FAULT_GENERAL_TAG_ERROR – 40Ah
FAULT_GEN2 PROTOCOL_OTHER_ERROR - 420h
FAULT_GEN2 PROTOCOL_MEMORY_LOCKED - 424h
FAULT_ANTENNA_NOT_CONNECTED – 503h
FAULT_TEMPERATURE_EXCEED_LIMITS – 504h
FAULT_HIGH_RETURN_LOSS – 505h
Lock Tag (25h)
For the deprecated version of this command see Appendix D: Lock Tag (25h) .
The Lock Tag command locks the specified memory bank of a tag. The tag which will be
locked can be specified using the
Tag Singulation Fields or, if Option=0x00 of the Tag
Singulation Fields is specified, it will attempt to lock the first tag it finds. If no tag is in the
field, the memory location doesn’t exist or is unlockable, or the Select criteria cannot be
satisfied a fault code is returned.
Note
Using Option=0x05 for the Tag Singulation Fields is not allowed for Lock Tag.
In addition to the Tag Singulation Fields the Lock Tag command takes several fields which
specify how the tag is to be locked. These fields are:
01 23 45 67 89 AB DC EF 01 23 45 67 11 11 22 22 00 00 00 00 81 E7
Select Data Write Data CRC
