Get Application Commands
Command Set 169
Get Application Commands
The Get commands listed in the following table are used to get settable parameters from
the Mercury Embedded module. All of the commands have a data length of zero, and
return data or a fault code.
Applications Commands – Get
Error Status Codes
FAULT_MSG_WRONG_NUMBER_OF_DATA – 100h
FAULT_MSG_INVALID_PARAMETER_VALUE - 105h
FAULT_AHAL_TRANSMITTER_ON – 502h
OpCode Command Name Bootloader App Firmware
0x10 Get Hardware Version (10h) Y Y
0x61 Get Antenna Configuration (61h) N Y
0x62 Get Read TX Power (62h) N Y
0x63 Get Current Tag Protocol (63h) N Y
0x64 Get Write TX Power (64h) N Y
0x65 Get Frequency Hop Table (65h) N Y
0x66 Get User GPIO Inputs (66h) N Y
0x67 Get Current Region (67h) N Y
0x68 Get Power Mode (68h) N Y
0x69 Get User Mode (69h) N Y
0x6A Get Reader Configuration(6Ah) N Y
0x6B Get Protocol Configuration (6Bh) N Y
0x6C Get Reader Statistics (6Ch) N Y
0x70 Get Available Protocols (70h) N Y
0x71 Get Available Regions (71h) N Y
0x72 Get Current Temperature (72h) N Y
