Application Tag Commands
148 Command Set
An example BlockPermaLock single tag command, locking Block 5, is:.
The response to the BlockReadLock command contains the current (for just a read
operation) or updated (for a lock operation) status of the memory blocks requested. The
format of the response is:
The same BlockPermaLock embedded in a Read Tag Multiple takes the following form:
FF 1A 2E 03 E8 00 42 01 11 11 22 22 00 00 00 00 10 E2 00
SOH Length OpCode Timeout (ms) Chip
Type
Option Sub
Cmd
Access Passwords Select Data Address Select
Length Selct
Data
00 01 03 00 00 00 00 01 04 00 ?? ??
RFU Read/
Lock
Mem
Bank Block Ptr Block
Range
Mask CRC
FF XX 2E 00 00 42 XX XX XX ... ?? ??
SOH Length OpCode Status Option Word
Count
Tag’s Lock Response Mask
(2*BlockRange bytes)
CRC
FF 21 22 02 00 04 03 E8 11 22 33 44 00 00 00 00 08 E2
SOH Length OpCode Options
(TID Mem)
Search
Flags
Timeout Access Password Select Data Address
(bits)
Select
Data
Length
(bits) Select
Data
01 0F 2E 00 00 00 40 01
Embd
Cmd
Count Embd
Cmd
Length Embd
Cmd
OpCode Embd Cmd
Timeout
(Not Used)
Chip
Type Option Sub
Cmd
00 01 03 00 00 00 00 01 04 00 ?? ??
RFU Read/
Lock
Mem
Bank Block Ptr Block
Range
Mask CRC
