SW Overview
26 Introduction
Pin-out of 12-pin Digital Communications Connector
SW Overview
The software (SW) for the embedded products consists of two separate programs that
coexist in flash memory:
The boot loader, which is started at power on, is not field upgradable. It is
programmed into flash when the module is manufactured.
The application firmware, which implements the actual reader functionality, is field
upgradable.
Pin # Signal
1 +5V
2 +5V
3 GND
4 GND
5 Digital Output 1
6 Digital Output 2
7 Digital Input 1
8 Digital Input 2
9 UART TTL RX from host
10 UART TTL TX to host
11 Mfg test purposes
12 Mfg test purposes
