Get Application Commands
Command Set 185
Get Available Protocols (70h)
The Get Available Protocols command returns the list of protocols that the reader is
capable of reading. The protocol codes are defined in
Get Current Tag Protocol (63h) . The
total number of protocols in the system cannot exceed 32. The command is generated as
follows:
The following Microprocessor response shows that the reader is capable of reading one
protocol – GEN2:
Get Available Regions (71h)
The Get Available Regions command returns the list of regions that the reader is
capable of working in. The total number of regions in the system cannot exceed 248. The
list of region codes are found in
Region codes . The command is generated as follows:
The response shows that this reader is capable of reading in four regions – NA, EU, KR,
and EU2:
FF 00 70 1D 7F
SOH Length OpCode CRC
FF 02 70 00 00 00 05 3B 75
SOH Length OpCode Status Protocol #1 CRC
FF 00 71 1D 7E
SOH Length OpCode CRC
FF 03 71 00 00 01 02 03 07 39 FF
SOH Length OpCode Status Region#1 Region#2 Region#3 Region#7 CRC
