Get Application Commands
184 Command Set
Get Statistics Response Fields
To request the Noise floor with TX on, including portID for all ports, send the following
command:
The response (from an M5e with two antennas), containing the RF On Time for each
antenna would look like:
To reset the RF On Time statistic send the following command:
Field Description
Status (2 bytes) Standard response status
Option (1 byte) Same as the Requested Value
Requested Statistics Flag (1 byte) Same as the Requested Value
For each individual statistics requested as part of the Requested Statistics Flag the following fields will be
repeated according to the Statistics Response value. They will be in bit value order.
Statistic Flag (1 byte) The bit corresponding to the requested statistic.
Data Length (1 byte) Indicates how many bytes are in this statistics response value.
Antenna Port ID Note: Only included when Option=0x02
Antenna port ID
1
of the following Statistic value.
Statistics Response Value (N bytes
as indicated by Data Length) The response value of the statistic as specified in Available Statis-
tics
Note: 1 - When Using a Multiplexer all antenna values correspond to the Logical Antenna Setting
antenna value.
FF 02 6C 02 08 XX XX
SOH Length OpCode Option Statistics Flag CRC
FF 08 6C 00 00 02 08 08 04 01 44 02 25 XX XX
SOH Length OpCod
e
Status Option Requested
Stats Flag
Stat Flag
(Noise)
Data
Length
Antenna
ID
Noise
floor
Antenna
ID
Noise
floor
CRC
FF 02 6C 01 01 4E 89
SOH Length OpCode Option Statistics Flag CRC
