Release Version 1.0.34
Appendix D: Deprecated and Modified Commands 243
To get the current region, send the following command:
The command generates the following reply, which indicates that the reader is set to the
NA region:
Get Transmit Mode (6Ah)
The Get Transmit Mode command returns the tranmit modethe M5e is current set to.
The available transmit modes are shown in the following table:
Available Transmit Modes
Send the following command to get the currrent transmit mode:
The example reply shows the current transmit mode setting:
FF 00 67 1D 68
SOH Length OpCode CRC
FF 01 67 00 00 01 B4 80
SOH Length OpCode Status Region CRC
Hex Transmit Mode
0x0000 High performance mode (disables low power mode)
0x0001 Low power mode (disables high performance mode)
FF 00 6A 1D 65
SOH Length OpCode CRC
FF 02 6A 00 00 00 01 BF D3
SOH Length OpCode Status Transmit Mode CRC
