ThingMagic M5e-Compact - Manual (Page 157)

Set Application Commands
Command Set 157
Set Current Tag Protocol (93h)
To select a protocol, send the Set Current Tag Protocol code to the reader. A table of
valid protocol codes is found in
Get Current Tag Protocol (63h) . The following example sets
the protocol to GEN2:
Only protocols that are enabled in the reader are available. These protocols are listed in
the version information for the application, described in
Get Boot Loader/Firmware Version
(03h) .
Note
Changing protocol parameters manually using Set Protocol Configuration (9Bh)
will maintain their value across changes in the current protocol using Set
Current Tag Protocol (93h) . Their values will NOT be reset if the protocol is
reset, only if the module is power cycled or the application firmware is
reloaded by a
Start Bootloader (09h) followed by a Boot Firmware (04h) .
Note
Calling Set Current Tag Protocol will reset the Tag Buffer.
Set Write TX Power (94h)
The Set Write TX Power command sets the default, module-wide, power level to use for
writing to tags. This is necessary because a write operation may require a different RF
power setting than a read command. The format and arguments of this command are
identical to the Set Read TX Power command:
Note
Power settings for individual logical antenna ports specified in Set Antenna’s
Power and Settling Time override the value set here.
FF 02 93 00 05 51 7D
SOH Length OpCode Current Protocol CRC
FF 02 94 09 C4 28 5B
SOH Length OpCode Power in centi-dBm CRC
