Get Application Commands
182 Command Set
a
Get Reader Statistics (6Ch)
The Get Reader Statistics command allows the user to get and reset various statistics on
the reader operation. The command takes the following fields:
Get Reader Statistics Request Fields
FF 03 6B 00 00 05 00 02 08 76
SOH Length OpCode Status Protocol Parameter Value CRC
Field Value
Option (1 byte) • 0x00 - Get statistics specified by the Statistics Flag
• 0x01 - Reset the specified statistic.
• 0x02 - Get requested statistics for each port and include port
ID in response.
• 0x03 - Get requested statistics for Request Ports.
Statistics Flag (1 byte) Each bit corresponds to a specific statistic to be returned. See the
Available Statistics table for bit values.
Requested Ports Length (1 byte) Note: Only include if Option = 0x03
Number of ports statistics are requested for. Indicates the number
(N) bytes to follow.
Requested Ports (N bytes) Note: Only include if Option = 0x03
Port ID of ports to return statistics for.
Note: When getting statistics for all ports the returned ports is impacted by the Available Configuration
Options | Check Antenna Connection.
• If checking is enabled then only values for connected/detectable antenna ports are returned.
• If checking is disabled then values for all antenna ports are returned. However, if a port is not
connected it is possible this command will fail with a FAULT_HIGH_RETURN_LOSS – 505h status.
