Application Tag Commands
Command Set
105
0x0000 in the
Action
field unlocks all the memory banks as long as all
memory banks exist and are lockable.
Examples
The following example shows an attempt to apply a temporary (not permanent) Write lock
on the EPC memory (Option=0x01) of a tag whose EPC
ID=0x111122223333444455556666 and whose access password=0x11223344:
Error Status Codes
FAULT_MSG_WRONG_NUMBER_OF_DATA – 100h
FAULT_MSG_INVALID_PARAMETER_VALUE - 105h
FAULT_NO_PROTOCOL_DEFINED – 401h
FAULT_PROTOCOL_INVALID_ADDRESS – 409h
FAULT_ANTENNA_NOT_CONNECTED – 503h
FAULT_TEMPERATURE_EXCEED_LIMITS – 504h
Kill Tag (26h)
For the deprecated version of this command see Appendix D:
The Kill Tag command kills the specified tag. The tag which will be killed can be specified
using the
or, if Option=0x00 of the Tag Singulation Fields is
specified, it will attempt to kill the first tag it finds. If no tag is in the field, the kill password
is zero, or the Select criteria cannot be satisfied a fault code is returned.
In addition to the Tag Singulation Fields the Kill command takes the tag’s Kill Password
and an extra 1 byte field for future use (RFU).
FF
18
25
03
E8
01
11
22
33
44
00
20
00
20
60h
11 11 22 22 33 33 44
44 55 55 66 66
9E
7A
SOH
Length
OpCode
Timeout (ms)
Option
Access Password
Mask Bits
Action Bits
Select
Data
Length
Select EPC ID
CRC
