Application Tag Commands
138 Command Set
ChangeConfig
The ChangeConfig command is used to toggle the bits of the G2i* tag’s ConfigWord (see
ConfigWord to Command Bit Address Map table). Specify a ‘1’ in the desired bit location of
the Config Data word of the command in order to toggle that bit.
Note
Different version of the G2i* tags support different features. See tag data
sheet for specific bits supported.
The ChangeConfig command can ONLY be sent in the Secured state, i.e. requires a non-
zero password. Caution should be used when embedding ChangeConfig in a
Tag
Inventory With Embedded Operations command. Since this command toggles the specified
bits, if the tag responds twice (or an even number of times) during an inventory round the
end result will be no change.
ConfigWord to Command Bit Address Map
Config Data Bit
Address
(LSB=bit 0)
G2i* ConfigWord Bit
Address (Hex)
Toggle Bit Description
15 0x200 Tamper Alarm Flag (read only)
14 0x201 External Supply Flag Digital Input (read only)
13 0x202 RFU
12 0x203 RFU
11 0x204 Invert Digital Output (reset at power up)
10 0x205 Transparent Mode On/Off (reset at power up)
9 0x206 Transparent Mode data/raw (reset at power up)
8 0x207 Conditional Read Range Reduction (permanently
stored in tag memory)
7 0x208 Conditional Range Redcution Open/Short (perma-
nently stored in tag memory)
6 0x209 Maximum Backscatter Strength (permanently stored in
tag memory)
5 0x20A Digital Output (permanently stored in tag memory)
4 0x20B Read Range Reduction On/Off (permanently stored in
tag memory)
3 0x20C Read Protect User Memory (permanently stored in tag
memory)
