320IS Plus Installation Manual - Appendix A 63
8.2.2 Using the ZZ EDP Command
The ZZ EDP command can be used to remotely query which annunciators are currently displayed on the
indicator front panel. The ZZ command returns the currently displayed weight and a decimal number
representing the LED annunciators currently lit. The format of the returned data is:
wwwwww uu zzz
where wwwwww uu is the current displayed weight and units, zzz is the annunciator status value (see Table 8-3). If
more than one annunciator is lit, the second number returned is the sum of the values representing the active
annunciators.
For example, if the annunciator status value returned on the ZZ command is 148, the gross, standstill, and lb
annunciators are lit: 148 represents the sum of the values for the standstill annunciator (16), gross mode
annunciator (128), and the lb/primary units annunciator (4).
8.3 Continuous Output (Stream) Format
Figure 8-1 shows the continuous output format sent to the
320IS Plus
EDP or printer port when the STREAM
parameter (SERIAL menu) is set to either EDP or PRN.
Figure 8-1. Continuous Output Data Format
8.4 ASCII Character Chart
Use the decimal values for ASCII characters listed in Tables 8-4 and 8-5 when specifying print format strings on
the
320IS Plus
PFORMT menu. The actual character printed depends on the character mapping used by the
output device.
Decimal
Value Annunciator
1 Tare
2 Count
4 lb
8 kg
16 Standstill
32 Center of zero
64 Net
128 Gross
Table 8-3. Status Codes Returned on the ZZ Command
ASCII 02
(decimal )
Polarity:
= Positive
<–> = Negative
<^> = Overload
<]> = Underrange
W eight data: 7 digits, right-justified, with
decimal point, leading zer o suppr ession.
Overload =
^^^^^^^
Under range = ] ] ] ] ] ] ]
Display overflow = OVERFL
L = pounds
K = kilogram
T = ton
G = grams
O = ounces
= none
G = Gross
N = Net
Status:
= valid
I = Invalid
M = In motion
O = Over/under range
or
ASCII 13, 10
(decimal )
P = count
