Page 44

38
320IS Plus Installation Manual
Figure 3-12. Digital Input Menu
Table 3-8. Digital Input Menu Parameters
3.2.8
Analog Output Menu
The ALGOUT menu is used only if the
320IS Plus
is used with the I/O Module option. If the I/O Module is
DIG IN Menu
Parameter
Choices
Description
Level 2 submenus
DIGIN1
DIGIN2
DIGIN3
DIGIN4
OFF
ZERO
TARE
NT/GRS
NET
GROSS
UNITS
PRIUNI
SECUNI
DSPTAR
PRINT
CLRCN
KBDLOC
HOLD
BATSTA
BATPAU
CLRTAR
CLRACC
ACCUM
ENTER
BATRUN
NEWID
Specifies the function activated by digital inputs 1 and 2.
• ZERO, NT/GRS (net/gross mode toggle), TARE, UNITS, and PRINT provide the same
functions as the front panel keys.
• DSPTAR displays the current tare value.
• CLRCN resets the consecutive number to the value specified on the CONSTU parameter
(PROGRM menu).
• KBDLOC disables the keypad while the digital input is held low.
• HOLD holds the current display. Releasing this input clears the running average filter.
• BATSTA starts or ends a batch routine, depending on the state of the BATRUN input.
• BATPAU pauses a batch routine when held low.
• CLRTAR clears the current tare.
• CLRACC clears the accumulator.
• ACCUM displays the current accumulator value.
• ENTER simulates pressing the ENTER key in weigh mode (for setpoint and checkweigh
value changes from the front panel).
• BATRUN allows a batch routine to be started and run, with BATRUN active (low), the
BATSTA input starts the batch; if BATRUN is inactive (high), BATSTA cancels the batch.
• GROSS, NET, PRIUNI, and SECUNI select gross, net, primary units or secondary display
modes.
• NEWID enters the ID number.
XXXXXXX
XXXXXXX
XXXXXXX
DIGIN1
BATSTA
BATPAU
GROSS
CLRCN
NET
PRIUNI
ALGOUT
DIGIN
SETPTS
PROGRM PFORMT
SERIAL
CALIBR
CONFIG
FORMAT
DIGIN2
VERS
CLRACC
UNITS
TARE
NT/GRS
OFF
ZERO
CLRTAR
SECUNI
DIGIN3 & 4
DSPTAR
ACCUM
ENTER
KBDLOC
HOLD
BATRUN
OFF
ZERO
TARE
NT/GRS
UNITS
ENTER
BATPAU
BATSTA
BATRUN
KBDLOC
HOLD
CLRCN
ACCUM
DSPTAR
GROSS
NET
PRIUNI
SECUNI
CLRTAR
CLRACC
CLRCN
GROSS
NET
CLRTAR
TARE
NT/GRS
ZERO
CLRACC
OFF
UNITS
SECUNI
PRIUNI
DSPTAR
ACCUM
ENTER
KBDLOC
HOLD
BATPAU
BATSTA
BATRUN
NEWID
NEWID
NEWID
