Page 10

4
320IS Plus Installation Manual
Toggle between gross,
net and piece count
mode
• Move down (vertically)
• Decrement value
N/A
Toggle between gross, net
and piece count mode
Press to enter an auto
tare or keyed tare
Enter
Enter
Perform a piece count
Toggle between primary
and secondary units
• Move left (horizontally)
• Previous
Move left (horizontally)
Select a sample size
Print using GFMT
Move right (horizontally)
Print using CFMT
• Turn on/off a setpoint
• View a setpoint
• Edit a setpoint
N/A
N/A
N/A
Display the current
accumulator value
N/A
N/A
N/A
Time and date entry
N/A
N/A
N/A
Display the tare value
N/A
N/A
Display the average piece
weight
Clear the displayed value
Clear the displayed value
N/A
N/A
Enter a decimal point
Enter a decimal point
N/A
N/A
Enter a numeric
parameter value
Enter a numeric
parameter value
N/A
Enter a sample size
Table 1-1. Indicator Display Key Functions
