7 setpoint menu, Setpoint menu, Figure 3-7. setpoint menu – Rice Lake 320IS Plus Intrinsically Safe Digital Weight Indicator - Installation Manual User Manual
Page 38

32
320IS Plus Installation Manual
Figure 3-6. Print Format Menu
3.2.7
Setpoint Menu
See Section 7.0 on page 56 for more information about configuration and using setpoints.
Figure 3-7. Setpoint Menu
GFMT
Display first 6
characters of format
(See Note)
NFMT
Display and edit
active character and
ASCII value
Delete active
character
Scroll right in format string
Scroll left in format string
Incr ement ASCII value of active character
Decr ement ASCII value of active character
Pr ess
to insert a space
befor e the active character
XXXXXXX
XXXXXXX
XXXXXXX
XXXXXXX
VERS
ALGOUT
DIGIN
PROGRM PFORMT
SERIAL
CALIBR
CONFIG FORMAT
XXXXXXX
SETPNT
Same as GFMT
SPFMT
Same as GFMT
NOTE: To change the active character,
use the numeric keypad to enter the new
ASCII value and press Enter (TARE).
Same as GFMT
CFMT
GROSSP
NETSP
RELSP
PAUSE
DELAY
WAITSS
Go to
A
Go to
B
XXXXXXX
SETPTS ALGOUT
DIGIN
PROGRM PFORMT
SERIAL
CALIBR
CONFIG
FORMAT
VERS
Same as SETPT1
SPCFG
BATCHN
OFF
AUTO
MANUAL
SETPT2 – SETPT8
OFF
SETPT1
TIMER
CONCUR
Go to
D
COUNTR
AUTJOG
COZ
–GROSS
NMOTON
NRANGE
–NET
BATPRO
Go to
C
For more information on setpoint order, refer to Section 7.0, Figure: 7-1.
