26 320IS Plus Installation Manual
DSPRAT 250MS
500MS
750MS
1SEC
1.5SEC
2SEC
2.5SEC
3SEC
4SEC
6SEC
8SEC Display rate — Sets the update rate for displayed values. Values are in milliseconds (MS)
or seconds (SEC).
Level 3 Submenus
UNITS LB
KG
OZ
TN
T
G
NONE Specifies primary unit for displayed and printed weight. Values are: LB=pound;
KG=kilogram; OZ=ounce; G=gram; TN=short ton; T=metric ton. Selecting NONE,
removes the primary units from print.
DECPNT 888888
888880
888800
8.88888
88.8888
888.888
8888.88
88888.8 Decimal point location — Specifies the location of the decimal point or dummy zeroes in
the primary unit display. Value should be consistent with local legal requirements.
DSPDIV 1D
2D
5D Display divisions — Selects the minimum division size for the primary units displayed
weight.
Secondary Units
UNITS KG
OZ
TN
T
G
NONE
LB Specifies secondary units for displayed and printed weight. Values are: LB=pound;
KG=kilogram; OZ=ounce; G=gram; TN=short ton; T=metric ton. An arbitrary unit may be
used by selecting NONE and specifying a multiplier set under MULT.
MULT 1.00000
number If a unit other than the presets is to be used, an arbitrary unit may be selected for
conversion to a desired unit. The value entered here is applied as a multiplier to the
primary unit - or to the calibration unit if the primary unit is set to OFF. If the primary unit is
changed after setting this value, the multiplier will also change. Only the first six significant
(non-zero) digits of the set value are stored.
FORMAT Menu
Parameter Choices Description
Table 3-3. Format Menu Parameters (Continued)
