62
320IS Plus Installation Manual
8.2
Status Messages
Two EDP commands, P and ZZ, can be used to provide status about the indicator. These commands are described
in the following sections.
8.2.1
Using the P EDP Command
The P EDP command returns the current displayed weight value to the EDP port, along with the units identifier.
If the indicator is in an underrange or overload condition, the weight value is replaced with ^^^^^^ (overload) or
_ _ _ _ _ _
(under range).
Error Code
Description
Binary Value
1
EEPROM physical
error
0000 0000 0000
0001
2
Virgin EEPROM
0000 0000 0000
0010
4
Parameter
checksum error
0000 0000 0000
0100
8
Load cell
calibration
checksum error
0000 0000 0000
1000
16
A/D calibration
checksum error
0000 0000 0001
0000
32
Print format
checksum error
0000 0000 0010
0000
64
Internal RAM
checksum error
0000 0000 0100
0000
128
External RAM error
0000 0000 1000
0000
256
No optical
communication
0000 0001 0000
0000
512
A/D physical error
0000 0010 0000
0000
1024
A/D reference error
0000 0100 0000
0000
2048
Count error
0000 1000 0000
0000
4096
Low battery
0001 0000 0000
0000
8192
Display error
0010 0000 0000
0000
16384
A/D underrange
0100 0000 0000
0000
32768
Overflow
1000 0000 0000
0000
Table 8-2. Error Codes Returned on XE Command
