320IS Plus Installation Manual - Print Formatting 53
6.0 Print Formatting
The 320IS Plus provides four print formats, GFMT, NFMT, CFMT, and SPFMT that determine the format of the
printed output when the
PRINT
key is pressed or when a KPRINT EDP command is received. If a tare has been
entered or acquired, NFMT is used; otherwise, GFMT is used.
Each print format can be customized to include up to 300 characters of information, such as company name and
address, on printed tickets. You can use the indicator front panel (PFORMT menu), EDP commands, or the
Revolution
® configuration utility to customize the print formats.
6.1 Print Formatting Commands
Table 6-1 lists commands you can use to format the gross and net print formats. Commands included in the
format strings must be enclosed between < and > delimiters. Any characters outside of the delimiters are printed
as text on the ticket. Text characters can include any ASCII character that can be printed by the output device.
The default GFMT, NFMT and SPFMT print formats use only the new line () command and the commands
for gross, net, and tare weights in displayed units (, , and ).
Command Description
Ticket Format
GFMT/NFMT/CFMT SPFMT
Gross weight in displayed units
 
Gross weight in non-displayed units
 
Net weight in displayed units
 
Net weight in non-displayed units
 
Tare weight in displayed units
 
Tare weight in non-displayed units
 
Accumulated weight in displayed units
 
Number of accumulator event (5-digit counter)
 
Time of last accumulator event
 
Date of last accumulator event
 
Setpoint captured value

Current setpoint number

Time
 
Date
 
Time and date
 
ID number
 
Consecutive number
 
Average piece weight in count mode Ö
Piece count Ö
Setpoint target value Ö
Setpoint preact value Ö
Setpoint mode (gross or net label) Ö
Space
New line, end of line termination
Table 6-1. Print Format Commands
