320IS Plus Installation Manual - Appendix A
61
8.0
Appendix A
8.1
Error Messages
The
320IS Plus
indicator provides a number of error messages. When an error occurs, the message is shown on
the indicator LED display. Error conditions can also be checked remotely by using the XE EDP command as
described in Section 8.1.2.
8.1.1
Displayed Error Messages
The
320IS Plus
provides a number of front panel error messages to assist in problem diagnosis. Table 8-1 lists
these messages and their meanings.
8.1.2
Using the XE EDP Command
The XE EDP command can be used to remotely query the
320IS Plus
for the error conditions shown on the front
panel. The XE command returns two 5-digit numbers in the format:
xxxxx yyyyy
where
xxxxx
contains a decimal representation of any existing error conditions as described in Table 8-2.
If more than one error condition exists, the number returned is the sum of the values representing the error
conditions. For example, if the XE command returns the number 1040, this value represents the sum of an A/D
reference error (1024) and an A/D calibration checksum error (16).
The second number returned (
yyyyy
) uses the same bit assignments as shown in Table 8-2 to indicate whether the
test for the error condition was run. For example, the value
yyyyy
= 63487 represents the decimal equivalent of the
binary value 1111 0111 1111 1111. Using the bit assignments in Table 8-2, this value indicates all tests were run.
Error Message
Description
Solution
E A/D
A/D physical error
Call Rice Lake Weighing Systems (RLWS) Service.
EEPERR
EEPROM physical error
EVIREE
Virgin EEPROM
Use TEST menu to perform DEFLT (restore defaults) procedure, then
recalibrate load cells.
EPCKSM
Parameter checksum error
EACKSM
A/D calibration checksum error
A/D converter requires recalibration. Call RLWS Service.
EFCKSM
Printer format checksum error
Call RLWS Service.
ELCKSM
Load cell calibration checksum error
Recalibrate load cells.
EIDATA
Internal RAM error
Call RLWS Service.
EREF
A/D reference error
A/D converter requires recalibration. Call RLWS Service.
LOBTRY
Low battery
ENOOPC
No optical communication
OVRFLW
Overflow
Weight value too large to be displayed.
EXDATA
External RAM error
CNTERR
Count error
DSPERR
Display error
Error
Internal program error
Check configuration. Run XE command (see Section 8.1.2 on
page 61) to determine error type.
Call RLWS Service if unable to clear error by cycling power or if error
recurs.
^^^^^^
Overflow error
______
A/D underrange
A/D reading < –4 mV. Check scale for binding or damage.
Table 8-1. 320IS Plus Error Messages
