Rice Lake 320IS Plus Intrinsically Safe Digital Weight Indicator - Installation Manual User Manual
Page 24

18
320IS Plus Installation Manual
Part Number
Description (Quantity)
Part Number
Description (Quantity)
45043
4 in. W/No. 8 Ground Wire
14626
8–32NC Hex Kep Nut
16892
Earth Ground Label
19538
1.25 x 1 Slotted Black Post
15627
PG–9 Metal Lock Nut
91852
PG–9 Metal Cord Grip
15626
PG–9 Black Cord Grip
82432
125 mA Encapsulated Time–Lag Fuse
50962
PCN–9 Black Nut
72916
Backplate
45042
SS Bonded Sealing Washer, #8
14862
8–32NC x 3/8 Screw
39037
Backplate Gasket
68216
Rice Lake Nameplate
42640
1/4 – 28NF x 1/4 Screw
44676
Bonded Sealing Washer, 1/4"
29635
SS Tilt Stand
68403
1/4 – 20 Two-Prong Black Knob
15144
1/4 x 1 x 1/16 Nylon Washer
100345
Reconditioned/Exchange 320IS Plus
Table 2-5. Hardware Replacement List
