320IS Plus Installation Manual - EDP Commands
47
Command
Description
Values
PRI.DECPNT
Primary units decimal position
8.88888, 88.8888, 888.888, 8888.88, 88888.8, 888888, 888880,
888800
PRI.DSPDIV
Primary units display divisions
1D, 2D, 5D
PRI.UNITS
Primary units
LB, KG, OZ, TN, T, G, NONE
SEC.UNITS
Secondary units
LB, KG, OZ, TN, T, G, NONE
SEC.MULT
Secondary units multiplier
0.00000–9999.99
DSPRATE
Display rate
250MS, 500MS, 750MS, 1SEC, 1500SEC, 2SEC, 2500MS, 3SEC,
4SEC, 6SEC, 8SEC
Table 5-4. FORMAT EDP Commands
Command
Description
Values
WZERO
Zero calibration
-999999 – 999999
WVAL
Test weight value
0 – 999999
WSPAN
Span calibration
-999999 – 999999
REZERO
Rezero
-999999 – 999999
LC.CD
Set deadload coefficient
±268435455
LC.CW
Set span coefficient
±268435455
Table 5-5. CALIBR EDP Commands
Command
Description
Values
EDP.BAUD
EDP port baud rate
300, 600, 1200, 2400, 4800, 9600, 19200, 38400
EDP.BITS
EDP port data bits/parity
8NONE, 7EVEN, 7ODD
EDP.TERMIN
EDP port termination character
CR/LF, CR
EDP.EOLDLY
EDP port end-of-line delay
0–255 (0.1-second intervals)
EDP.ADDRESS
EDP port address
0-255
EDP.PORT
EDP port selection
RS232, RS422, RS485, CRLOOP, NONE
EDP.ECHO
EDP port echo
ON, OFF
EDP.RESPONSE
EDP port transmit replies
ON, OFF
PRN.BAUD
Printer port baud rate
300, 600, 1200, 2400, 4800, 9600, 19200, 38400
PRN.BITS
Printer port data bits/parity
8NONE, 7EVEN, 7ODD
PRN.TERMIN
Printer port termination character
CR/LF, CR
PRN.EOLDLY
Printer port end-of-line delay
0–255 (0.1-second intervals)
PRN.ADDRESS
Printer port address
0-255
PRN.PORT
Printer port selection
RS232, RS422, RS485, CRLOOP, NONE
PRN.ECHO
Printer port echo
ON,OFF
PRN.RESPONSE
Printer port transmit replies
ON, OFF
STREAM
Streaming port
OFF, EDP, PRN
PRNDEST
Print destination
EDP, PRN
Table 5-6. SERIAL EDP Commands
