Dynojet 250i: Pit Installation Guide User Manual
Page 89
A C C E S S O R I E S
Air Brake
Version 4
In Ground Model 200iP/250iP Motorcycle Dynamometer Installation Guide
3-11
7
Using a 9/16-inch ratchet and wrench, remove the bolt, washer, and nut securing
the spring to the brake assembly. The spring is located on the drum side of the
brake assembly.
Figure 3-12: Remove the Brake Spring
bolt
bolt
nut, washer, and spring
nut, washer,
and spring
