Installing the eddy current brake – Dynojet 250i: Pit Installation Guide User Manual
Page 35

I N S T A L L A T I O N
Eddy Current Brake
Version 4
In Ground Model 200iP/250iP Motorcycle Dynamometer Installation Guide
2-13
I
NSTALLING
THE
E
DDY
C
URRENT
B
RAKE
Safety requirements of your local country may require that both the air brake and the
eddy current brake are installed. Be sure to follow the safety requirements specific to
your country.
1
Insert the key into the keyway on the dyno drum module shaft.
2
Use a c-clamp to press the key in.
Figure 2-8: Install the Key
key way on dyno shaft
key
