Dynojet 250i: Pit Installation Guide User Manual
Page 82
In Ground Model 200iP/250iP Motorcycle Dynamometer Installation Guide
C H A P T E R 3
Air Brake
3-4
5
Route the air brake air hose through the access hole in the drum module upright
and through the pit conduit.
6
Connect your clean, dry shop air supply (60 psi, 415 kilopascal, max constant line
pressure) to the air hose.
Figure 3-3: Connecting the Air Hose
PD179
air brake
pit conduit
access hole
to 60 psi
clean dry air
