Dynojet 250i: Pit Installation Guide User Manual
Page 113
B A S I C D Y N O O P E R A T I O N
Loading the Motorcycle
Version 4
In Ground Model 200iP/250iP Motorcycle Dynamometer Installation Guide
5-3
5
With the motorcycle in neutral, align the wheel in the center of the knurl. If you
have a battery installed, you may align the wheel by pressing the dyno starter
switch.
Figure 5-1: Align the Wheel and Axle
tire stop
tire strap
adjust carriage to align
rear axle with drum
center drive axle
on dyno drum
