Dynojet 250i: Pit Installation Guide User Manual
Page 17
S P E C I F I C A T I O N S A N D O P E R A T I N G R E Q U I R E M E N T S
Dynamometer Specifications and Requirements
Version 4
In Ground Model 200iP/250iP Motorcycle Dynamometer Installation Guide
1-7
Figure 1-2: Model 250iP Dyno with Accessories
PD154
High Pressure
Blower
Eddy Current
Brake Module
Air Brake Option
(not shown)
Air Pump Option
(not shown)
Power Carriage
(not visible)
Monitor Support
and Tray
Dyno Module
Control Panel
Control Panel
Interface
houses all electronics
(not shown)
Wheel Clamp Option
