Eec f – Dynojet 250i: Pit Installation Guide User Manual
Page 141
In Ground Model 200iP/250iP Motorcycle Dynamometer Installation Guide
C-1
A
P P E N D I X
C
EEC F
INGER
G
UARD
AND
D
OOR
S
AFETY
S
WITCH
I
NSTALLATION
This appendix contains instructions for installing the EEC Kit to the in ground model
200iP/250iP motorcycle dynamometers. This appendix will walk you through
installing the EEC finger guards and door safety switch. The finger guards and door
safety switch are required only for European dynamometers. To ensure safety and
accuracy in the procedures, perform the procedures as they are described.
For more information refer to the Air Brake and EEC Kit Installation Guide,
P/N 98123114.
