I N S T A L L A T I O N
Eddy Current Brake
Version 4
In Ground Model 200iP/250iP Motorcycle Dynamometer Installation Guide
2-15
11 Replace the existing set screws on the driveline with the thread-lock set screws
provided.
12 Tighten the driveline set screws.
Figure 2-10: Tighten the Set Screws
brake shaft
dyno shaft
set screw
