In Ground Model 200iP/250iP Motorcycle Dynamometer Installation Guide
C H A P T E R 2
Dyno Drum Module Installation
2-4
cable hole cover track
mount
P/N 21228520
tire stop
P/N 63310902
not included if you ordered
the optional wheel clamp
junction box cover
P/N 21228521
control panel button sub-
assembly
P/N 66117001
drum guard, side (2)
P/N 21229111
standard carriage
P/N 71323006
or
extended carriage
P/N 71323007
see list of parts below
drum guard mounting
bracket
P/N 21624103
wheel clamp
P/N 71329000
optional accessory
cable track mounting
bracket
P/N 21626217
control panel interface
(CPI)
P/N 76129010
cable track adapter bracket
P/N 21626218
dyno electronics assembly
P/N 76199001P
cable cover, pit to junction
box
P/N 21626902
blower assembly
P/N 76722005
optional accessory
see list of parts below
screw, 8-32 x 3/8", pan-head,
phil (13)
P/N 36540643
banner, dynojet (2)
P/N D706
part description part description
