Dynojet 250i: Pit Installation Guide User Manual
Page 65
I N S T A L L A T I O N
Routing Cables
Version 4
In Ground Model 200iP/250iP Motorcycle Dynamometer Installation Guide
2-43
5
Close the CPI front access panel. Refer to page 2-31.
Figure 2-37: Wire the Breakout Board
temp
load control
pick-up card
J2 J1
J1
J2
eddy current brake only or
eddy current brake and air
brake with control panel
air brake
only
