Configuring the IP route (optional)
Use the following procedure to configure the IP route.
NOTE
You can create maximum of 32 static IP routes.
1. Launch the iSCSI Target Gateway Admin module as described on
.
2. Select the iSCSI Port tab.
3. From the left pane, select the GbE port to use.
4. Select the IP Routes tab.
5. Click Add.
6. Enter the IP address, subnet mask, and gateway IP address, and the metric.
7. Click Add.
Editing the IP route
Use the following procedure to edit an IP route.
1. Open the iSCSI Target Gateway Admin module as described in
2. Select the iSCSI Port tab.
3. From the left pane, select the GbE port to use.
4. Select the IP Routes tab.
5. Click Edit. A warning dialog box displays.
6. Click OK.
7. Enter a new value for the metric.
8. Click OK.
NOTE
If you want to change a value other than the metric, you must delete this route and create
another in its place.
Creating iSCSI virtual targets
SCSI virtual target creation is done from the first pane in the iSCSI Target Gateway Admin module.
The iSCSI Virtual Target wizard provides two ways to create iSCSI targets: Create and Easy Create.
Create allows you to double check your work several times before committing the changes.
Use the following procedure to create an iSCSI virtual target.
1. Open iSCSI Target Gateway Admin module as described in
2. Select the Targets tab.
3. Click Create.
