Web Tools Administrator’s Guide 223
53-1001772-01
SNMP configuration
17
DRAFT: BROCADE CONFIDENTIAL
3. Enter a contact name, description, and location in the SNMP Information section.
4. Optional: Select the Enable Authentication Trap check box to allow authentication traps to be
sent to the reception IP address.
5. Click Apply.
Setting SNMPv1 configuration parameters
Use the following procedure to set SNMPv1 configuration parameters.
1. Open the Switch Administration window as described in “Opening the Switch Administration
window” on page 35.
2. Select the SNMP tab.
3. Double-click a community string in the SNMPv1 section and enter a new community string.
4. Double-click a recipient IP address in the SNMPv1 section and enter a new IP address.
5. Click Apply.
Setting SNMPv3 configuration parameters
NOTE
The port number is not included.
Use the following procedure to set SNMPv3 configuration parameters.
1. Open the Switch Administration window as described in “Opening the Switch Administration
window” on page 35.
2. Select the SNMP tab.
3. Select a user name from the User Name menu in the SNMPv3 section.
NOTE
The list is scrollable. If you do not see your user name, scroll down using the scroll bar or by
clicking the User Name heading.
4. Double-click a recipient IP address in the SNMPv3 section and enter a new IP address.
5. Select a trap level from the Trap Level menu.
6. Optional: Select the Enable SNMPv3 Informs for all Trap Recipients check box to enable or
disable inform requests for all trap recipients.
7. Enabling SNMPv3 informs allows you to enter the Engine ID.
The Engine ID is required to authenticate the inform request. If informs request is disabled, the
SNMP manager does not send a response to the sender.
8. Click Apply.
