Web Tools Administrator’s Guide 97
53-1001772-01
Configuring BB credits on an F_Port
6
DRAFT: BROCADE CONFIDENTIAL
Determining if a port index was swapped
with another switch port
Use the following procedure to determine whether a port was swapped.
1. Select a port in the Switch View to open the Port Administration window.
2. Select the FC Ports tab.
3. Click Show Advanced Mode.
4. From the tree on the left, select the port you want to swap.
5. Click the General tab.
NOTE
The Port Index attribute on the General tab indicates whether a port was swapped. For ports
that were swapped, the attribute name displays as Port Index (Swapped), as shown in
Figure 31 . The value indicates with which port index the port was swapped.
FIGURE 31 Port swapping index
Configuring BB credits on an F_Port
In Fabric OS v6.4.0 and later, you can configure the BB credits value on an F_Port. Follow the steps
given below.
1. Select a port in the Switch View to open the Port Administration window.
2. Select the FC Ports tab.
