Web Tools Administrator’s Guide 229
53-1001772-01
IPsec concepts
17
DRAFT: BROCADE CONFIDENTIAL
From Web Tools, you can establish IPsec policies for FCIP implementations on 7800 extension
switches with the upgrade license, the 7500 extension switches and FR4-18i blades, and you can
establish IPsec policies for IP interfaces that provide management access to switches and control
processors.
There are several protocols and algorithms that can be applied. Choosing the protocols and
algorithms you want to use may be a matter of adapting to an implementation that is already in
place in your LAN, or you may need to do a significant amount of research and planning. The
supported protocols and algorithms are defined and described in the RFCs listed in
Table 19 .
Transport mode and tunnel mode
Transport mode adds an authentication header (AH) before the IP header. Only a single pair of
addresses is used (those in the IP header). When transport mode is used, both endpoints
implement IPsec.
Tunnel mode encapsulates an IP datagram in a new datagram, with a new IP header specifying the
addresses of the tunnel end points. IPsec is implemented between tunnel endpoints. IPsec is
transparent to the actual endpoints within the IP header in the original packet.
TABLE 19 Relevant RFCs
RFC number Title
RFC 4301 Security Architecture for the Internet Protocol
RFC 4302 IP Authentication Header
RFC 4303 IP Encapsulating Security Payload
RFC 4304 Extended Sequence Number (ESN) Addendum
to IPsec Domain of Interpretation (DOI) for
Internet Security Association and Key
Management Protocol (ISAKMP)
RFC 4305 Cryptographic Algorithm Implementation
Requirements for Encapsulating Security
Payload (ESP) and Authentication Header
RFC 4869 Suite B Cryptographic Suites for IPsec
RFC 4309 Using Advanced Encryption Standard (AES)
CCM Mode with IPsec Encapsulating Security
Payload (ESP)
RFC 4306 Internet Key Exchange Version 2 (IKEv2)
Protocol
RF C4307 Cryptographic Algorithms for Internet Key
Exchange Version 2 (IKEv2)
RFC 3971 Secure Neighbor Discovery
RFC 3972 Cryptographically Generated Addresses
RFC 3041 Privacy Extensions for Stateless Address Auto
configuration in IPv6
