Control Panel
51
22 One touch panels
(Only available for machines
with the Fax service)
Contains one touch buttons.
Turn over the panels to display buttons 1 - 70, M01, and M02.
There are two ways in which address numbers and stored programs are
assigned to the one touch buttons. Select either of the following:
• [Type 1]
The buttons 1 to 70 are used for address numbers and they correspond to
the registered address numbers 0001 to 0070, while the buttons M01 and
M02 are used for stored programs and they correspond to the registered
stored programs 1 and 2.
• [Type 2]
The buttons 1 to 60 are used for address numbers and they correspond to
the registered address numbers 0001 to 0060, while the buttons 61 to 70,
M01, and M02 are used for stored programs and they correspond to the
registered stored programs 1 to 12.
Note • By default, [Type 1] is selected.
• An optional component is required to use this feature. For more
information, contact Customer Support at dell.com/contactdell.
For information on how to change the settings registered to the one touch
buttons, refer to "Screen/Button Settings" (P.319).
23 One touch buttons
(Only available for machines
with the Fax service)
Allows you to specify a recipient with the simple press of a button. You can
use the buttons for the Fax, Internet Fax, Scan (E-mail), and Scan to PC
jobs.
Turn over the panels to display buttons 1 - 70, M01, and M02.
There are two ways in which address numbers and stored programs are
assigned to the one touch buttons. Select either of the following:
• [Type 1]
The buttons 1 to 70 are used for address numbers and they correspond to
the registered address numbers 0001 to 0070, while the buttons M01 and
M02 are used for stored programs and they correspond to the registered
stored programs 1 and 2.
• [Type 2]
The buttons 1 to 60 are used for address numbers and they correspond to
the registered address numbers 0001 to 0060, while the buttons 61 to 70,
M01, and M02 are used for stored programs and they correspond to the
registered stored programs 1 to 12.
Note • By default, [Type 1] is selected.
• An optional component is required to use this feature. For more
information, contact Customer Support at dell.com/contactdell.
For information on how to change the settings registered to the one touch
buttons, refer to "Screen/Button Settings" (P.319).
24 Paper clip tray Used for placing paper clips and staples.
No. Component Function
