2.2 Principle of data input
751 GPD Titrino
5
2.2 Principle of data input
• If you press a key you will find a group of inquiries in
the display.
Example key :
In the first line you see where you are: You pressed
key and you are now in the inquiries
"configuration".
• The cursor is inverted. In our example the cursor is
on the inquiry ">monitoring". You can move the cur-
sor up and down with keys < ↑ > and < ↓ >.
• If a dialog text is marked with ">", it contains a
group of inquiries itself. You go to this group press-
ing .
Example inquiries of "peripheral units":
The first two lines indicate again where you are.
Then you find the inquiries.
If a dialog text of an inquiry is marked with ":", you
can select a value with keys < ← > and < → >
(forward/backward).
• A value is stored with and the cursor
moves to the next inquiry.
• With key you move one level up, in our ex-
ample you go back to ">peripheral units".
If you press once more you quit the in-
quiries in "configuration" altogether.
• If you can scroll, ↓ or ↑ appear in the right lower or
upper corner of the display.
configuration
>monitoring
>peripheral units
>auxiliaries
>RS232 settings COM1
>RS232 settings COM2
>common variables
>prep.dosing elements
configuration
>peripheral units
send to COM1: IBM
send to COM2: IBM
man.reports to COM: 1
balance: Sartorius
stirrer control: OFF
remote box: OFF
configuration
>monitoring
>peripheral units
>auxiliaries
>RS232 settings COM1
>RS232 settings COM2
>common variables
>prep.dosing elements
