3.2. Remote control commands
751 GPD Titrino
168
IInfo.D
.DetermData.E
.ExV
read only/read+write
IInfo.D
.DetermData.M
.MPList.1.X
.1.X
read only/read+write
IInfo.D
.DetermData.M
.MPList.1.Y
.1.Y
read only/read+write
IInfo.D
.DetermData.M
.MPList.1.Z
.1.Z1
read only/read+write
IInfo.D
.DetermData.M
.MPList.1.Z2
.1.Z2
read only/read+write
for every measuring point
Determination data in hexadecimal format. A measuring point list is available in
mode DET, MET, STAT, DOS, DOC, SET, KFT, and MEAS.
Recalculation of the measuring data is triggered with $G.
.Write:
With "ON", the following nodes can be overwritten:
&Info.DetermData.MP.List, &Info.TitrResults.Var.C4X (X = 0...5),
&Info.TitrResults.TempVar.C7X (X = 0...9), and &Mode.Name.
.ExV:
Volume of the exchange unit, with which the determination was
executed
.MPList.1.Attribute: Attribute
.MPList.X: X coordinate, time
.MPList.Y: Y coordinate, volume
.MPList.Z1: Z1 coordinate, measuring value
.MPList.Z2: Z2 coordinate, temperature
3.2.2.
3.2.2.135.
135. IInfo.T
.TitrResults.R
.RS.1.V
.1.Value
read only
etc., up to .9
.9
IInfo.T
.TitrResults.E
.EP.1.V
.1.V
read only
IInfo.T
.TitrResults.E
.EP.1.M
.1.Meas
read only
etc., up to .2
.2
IInfo.T
.TitrResults.V
.Var.C
.C40
read only/read+write
etc., up to .C47
.C47
IInfo.T
.TitrResults.V
.Var.DTime
read only/read+write
.RS
.RS: Values of the calculated results.
.EP
.EP: Endpoints with DET, MET, SET, KFT:
Volume coordinate in mL, e.g. "1.2340"
Measured value coordinate in pH "5.12", mV (with U and Ipol) "-
241" or uA (with Upol) "43.7".
..Var
Var: Various variables. You may overwrite the variables C40...C45, see
3.2.2.134.
C40: Initial measured value in pH "5.12", mV (with U and Ipol) "41",
uA (with Upol) "43.7" or °C (with T) "25.0". In MEAS final measured
value.
C41: End volume with SET, STAT, DOS, DOC in ml, "12.5360".
C42: Time from start of titration to end in s, "62".
C43: Volume drift on start of a SET/KFT titration from the condi-
tioning in ul/min, "3.5".
C44: (Last measured) temperature in °C. Used for the temperature
compensation in pH measurements.
C45: Start volume with SET, STAT, DOC in ml, "2.800".
C46: Asymmetry pH of CAL, "6.89".
C47: Relative electrode slope of CAL, "0.9950".
C48: Voltage at maximum voltage (not valid in CAL and TIP)
C49: Voltage at minimum voltage (not valid in CAL and TIP)
DTime: Dosing time in s in DOS/DOC or time for the drift correction
in SET/KFT with conditioning, resp.
