5 Method
viva 1.1
￭￭￭￭￭￭￭￭ 529
[Delete]
Deletes the calculated measured value selected in the table.
Additional external measured values
Additional external measured values
on | off (Default value: off)
If this check box is activated, then a maximum of three new measured val-
ues can be adopted from other measuring commands (e.g. MEAS) and
saved that can also be displayed as curves under the designation External
1 - 3 and be used as variables 'Command name.EX1 - 3' in formulas.
[New]
Opens the External measured value # dialog window, in which the
parameters for the external measured value can be entered (see Chapter
5.5.2.7.8.2, page 551).
[Properties]
Opens the External measured value # dialog window, in which the
parameters for the external measured value can be edited (see Chapter
5.5.2.7.8.2, page 551).
[Delete]
Deletes the external measured value selected in the table.
5.5.2.7.4.6 MEAS Opt - Fixed point evaluation
Dialog window: Method ▶ MEAS Opt ▶ Properties... ▶ Evaluations ▶ Fixed point
evaluation #
Measured quantity
Selection of the fixed measured quantity to which the associated values
for the other quantities are to be interpolated from the list of measured
points.
Selection Measured value | Time
Default value Measured value
Fixed value
Value of the fixed point.
Measured value
Input range
0 - 4,000 mAU
Time
Input range
0.0 - 999999.9 s
