71
Chapter 7 PC Tool
Bird’s SignalHawk PCTool enables the use of a PC to store measure-
ment data, transfer it between units, and do individual analysis. Traces
can be transferred from the SignalHawk to the PC and back. One or
more saved traces can be opened and compared. They can also be copied
and pasted into other open files, as well as adding markers or limit
lines. In addition, labels can be added and modifications saved to files.
Note:
Not all sections of this chapter apply to the PC and
Rack Mount SignalHawks.
Computer Requirements
The PC must meet the following minimum requirements:
z Windows 98 or later operating system
z Internet Explorer version 6 or later
z Hard disk with 30 MB of free space
Downloading and Installing Software
Note:
These files are on the CD supplied with the Signal-
Hawk, and can also be downloaded from the website.
Note:
For the latest versions of the PCTool, Microsoft
®
ActiveSync
®
, and USB Drivers download them from the Bird
Technologies SignalHawk website.
For PC:
http://birdtechnologies.thomasnet.com/item/all-categories-test-
equipment/-categories-test-equipment-sh-36-signalhawk-series/
sh-36s-pc
For Rack Mount
:
http://birdtechnologies.thomasnet.com/item/all-categories-test-
equipment/-categories-test-equipment-sh-36-signalhawk-series/
sh-36s-rm
Installing the PC Tool Software
1. Download and install Microsoft ActiveSync.
2. Click on “Install PC Interface Tool.”
3. Save the compressed file to the PC’s desktop.
4. Double click the compressed file on the PC desktop.
5. Click-and-drag the SHPCTool icon (Setup file) out of the com-
pressed file window and onto the PC desktop.
6. Double-click the Setup file.
7. Follow the instructions in the Install Wizard to complete the installation.
