background image

Maintenance

87

Specifications

SH-36S-RM

Model Number

Model Name

SH-36S-RM

Rack-Mount SignalHawk

SH-36S-PC

PC SignalHawk

Frequency

Range

100 kHz to 3.6 GHz

Resolution

1 Hz

Uncertainty

± 1 ppm (2

σ

) of measured frequency

Aging

± 1 ppm / year (2

σ

)

Temperature Drift

± 1 ppm / °C (2

σ

)

Span

1 kHz to 3.5999 GHz; 0 Hz (zero span)

Spectral Purity, Max @ 1 GHz

30 kHz from carrier

-85 dBc / (RBW Hz)

1/2

100 kHz from carrier

-100 dBc / (RBW Hz)

1/2

1 MHz from carrier

-124 dBc / (RBW Hz)

1/2

Sweep Time:

15.5 ms per data point to >2000 s, full span;

1 ms to 100 s, zero span

Displayed Data Points

705

Resolution Bandwidth
(RBW):

100 Hz to 1 MHz in 1, 3, 10 steps

Video Bandwidth (VBW):

10 Hz to 300 kHz in 1, 3, 10 steps

Amplitude

Display Range

-150 dBm to +30 dBm

Intermodulation-Free
Dynamic Range

66 dB; Third-order IM products,

Two -20 dBm inputs, Reference = -10 dBm

Displayed Average
Noise Level (DANL)

-135 dBm; 24 dB gain, 100 Hz RBW,

10 Hz VBW, average detection

Inherent Spurious

–80 dBm; reference ≤ –10 dBm, f > 30 MHz,

RBW ≤ 100 kHz

Input Related Spurious

–70 dBc; mixer level ≤ -30 dBm, carrier offset

≥ 1 MHz

Reference Level

-140 dBm to +30 dBm

Attenuator

Built-in: 0, 10, 20, 30 dB

Pre-Amp

Built-in: +24 dB

Resolution

dB-based units

W or V-based units

1 to 15 dB per division in 1 dB steps

1%, 2%, 5%, or 10% of reference level per

division

Units

dBm, µW, mW, W, dBµV, dBmV, dBV, µV, mV,

V, dB/m

2

, µV/m

2

Offset Range

-99 to +99 dB
