Detection Modes
Sample, +peak, –peak, average, video average
Trigger Modes
Single, free run
Trigger Sources
Internal, external TTL, internal video
External Trigger Types
Rising edge, falling edge, any edge, trigger on HIGH,
trigger on LOW
External Trigger Level
TTL Levels
External Trigger Delay
User-settable, 100 µs to 1000 ms after trigger received
before starting sweep
External Trigger Connector
BNC(F)
Markers
6 Markers; Modes: On/Off, Standard, Marker to Max
Peak, Marker to Next Peak, Marker Freq to Center,
Marker Ampt to Ref Level, Marker Delta, Marker
Type Line/Icon, Marker Noise, All Marker to Peaks,
All Markers Off. Also, Marker to Max/Min Peak
General Specifications
Model
Name: Hand-Held, PC SignalHawk
Model: SH-36S-PC
Description: PC-based Spectrum Analyzer
Housing
Aluminum Case, Plastic corner protectors
Power Indicator
Green LED
Charge Indicator
Green/Amber LED – Amber: low battery or charging,
Green: fully charged.
Connectors
N(F) for RF input
2.1 mm DC jack for AC adapter/charger external power
USB Type B for PC connection
BNC(F) for external trigger
RF Input Impedance
50 ohms, nominal
RF Input VSWR
1.8:1 typ, 2.0:1 max
(internal attenuator = 10dB or greater)
Max DC Input
± 50 V
Max RF Input
+20 dBm; damage level is +30dBm for 30 sec.
AC Adapter/Charger
External DC power supply, 15 VDC, 3 A, 2.1mm pin
connector
Internal Battery
Rechargeable, field replaceable, lithium-ion battery.
5.5 hours continuous operation, 25°C.
Warm-Up
Specifications apply after a 30 minute warm-up period
at ambient temperature. Typical values are provided
for reference and are not guaranteed.
Operating Temperature
0 to 50 °C (MIL-PRF-28800F, Class 3)
Storage Temperature
–20 to +80 °C
Note:
If storing above 60°C for prolonged
periods it is recommended that the battery be
stored separately
Humidity, Max
95% non-condensing (MIL-PRF-28800F, Class 2)
Measurements
