Bird Technologies

88

Accuracy

± 1.5 dB max (2

σ

), ±1.0 dB typical,

>-50 dB ref, 15 to 35 °C, max detector

Averaging

Running display average, 2 to 100 sweeps

Detection Modes

sample, +peak, –peak, average, video

average

Measurements

Spectrum Analysis

Analyzes radio frequency spectrum. Measures
intended and interfering signals. Allows setup
of parameters such as frequency, amplitude
and markers. Graphically displays signals
amplitude vs. frequency and saves traces
internally or to a compatible PC. Allows remote
logging & monitoring.

Worldwide Applications

Cellular, PCS, DCS, 2 G, 3 G, CDMA,
cdmaOne, CDMA 2000, 1x, 1x EV-DO, GSM,
GPRS, EDGE, UMTS, HSDPA, W-CDMA,
TDMA, AMPS as well as 802.11, Bluetooth,
Broadcast, Emergency, Fire, GPS, Microwave,
NPSPAC, Paging, Police, Private, Project 25,
Public Safety, Tactical Military, Telematics,
Tetra, Trunking, Utilities, WLAN and WLL.

Predefined Measurements

Spectrum Analysis, Occupied Bandwidth (OBW),
Channel Power, Adjacent Channel Power Ratio
(ACPR), Arbitrary Power Range, Field Strength,
Zero Span, AM/FM Demodulation, Carrier-to-
Interference Ratio (C/I), and Frequency Counter.
The user manual includes step-by-step
procedures for these one-button measurements
as well as Out-of-Band Spurious and In-Band,
Out-of-Channel Spurious measurements.

Help Functions

Help menu displays on-board user manual
and customizable help files.

Travel Logging

Sample rate 60 to 3600 sec.

Internal Trace/Setup Storage
Capacity

140 Gb

Trigger Modes

Single, free run

Trigger Sources

Internal, external TTL, internal video

External Trigger Types

Rising edge, falling edge, any edge, trigger on
HIGH, trigger on LOW

External Trigger Level

TTL Levels

External Trigger Delay

User-settable, 100 µs to 1000 ms after trigger
received before starting sweep

External Trigger Connector

BNC(F)

Amplitude
