Maintenance
91
Distortion & DANL
SH-36S-PC
Client Priority
Local USB client, single client only (local or
remote)
Input
Connector
Precision N-F
RF Input Impedance
50 ohms, nominal
RF Input VSWR
1.8:1 typ, 2.0:1 max
(internal attenuator = 10dB or greater)
Max DC Input
± 50 V
Max RF Input
+20 dBm; damage level is +30dBm for 30 sec.
Frequency
Range
100 kHz to 3.6 GHz
Resolution
1 Hz
Uncertainty
± 1 ppm (2 σ ) of measured frequency
Aging
± 1 ppm / year (2
σ
)
Temperature Drift
± 1 ppm / °C (2 σ )
Span
1 kHz to 3.5999 GHz; 0 Hz (zero span)
Spectral Purity, Max @ 1 GHz
30 kHz from Carrier
100 kHz from Carrier
1 MHz from Carrier
-85 dBc / (RBW Hz)
1/2
-100 dBc / (RBW Hz)
1/2
-124 dBc / (RBW Hz)
1/2
Sweep Time
15.5 ms per data point to >2000 s, full span;
1 ms to 100 s, zero span
Displayed Data Points
705
Resolution Bandwidth (RBW)
100 Hz to 1 MHz in 1, 3, 10 steps
Video Bandwidth (VBW)
10 Hz to 300 kHz in 1, 3, 10 steps
PC Software
