FS1-X v1.1 www.aja.com 89
8.0 HDMI Audio Out
See “1.0 SDI1 Audio Out” on page 87
9.0 Analog Audio
Out
See “1.0 SDI1 Audio Out” on page 87
11 Global Output
This parameter allows routing the same source or set of sources to all the FS1-X outputs.
The rules used for Audio Out apply if the number of outputs do not match the number of
inputs.
NOTE: When any Global Output other than Off has been selected, and Hidden Menus is set to Hide
Inactive, no other AUDIO OUTPUT menu group menus will be accessible (they are hidden).
NOTE: No Global Map source is available.
12 Reset Mapped
Output
This parameter resets the selected output map to the factory default values
Off (default) No Global output configuration is imposed. When Off all other
AUDIO OUTPUT menus are enabled and displayed.
SDI1
SDI2
Fiber1
Fiber2
AES/EBU
MADI BNC
MADI Fiber
HDMI
Analog The selected source channels are routed to all the FS1-X output
channels. If the output has more channels than the source, mute
(silence) is routed to the higher numbered output channels. If the
output has fewer channels than the source, the sources are routed
to the lower numbered output channels.
Sig Gen 1KHz
Sig Gen 400Hz
Mute The selected tone or mute is routed to every FS1-X output channel.
Mix Down 1 L:R
Mix Down 2 L:R The stereo output of Mix Down 1 or Mix Down 2 is routed to all the
FS1-X output channels. The Left mixer channel goes to FS1-X
output channel 1 and the Right mixer channel goes to output
channel 2. If the output has more than two channels (i.e.
embedded SDI), mute (silence) is routed to the higher numbered
output channels.
Choose a Map (default) Prompt for selecting an Output to map.
SDI1
SDI2
Fiber1
Fiber2
AES/EBU
MADI BNC
MADI Fiber
HDMI
Analog
All After selecting an output, press ADJUST to reset that output to the
factory default (i.e. SDI1 to SDI1, SDI2 to SDI2, etc.).
All sets all outputs to their factory defaults.
