FS1-X v1.1 www.aja.com 60
6 Fiber1 3G Detect
This parameter configures 3G operation of the Fiber 1 video input, using settings similar
to
“4 SDI1 3G Detect” on page 58 .
7 Fiber2 Input
Protect
This parameter allows you to protect Input Fiber 2 from being taken by a Dual Stream
selection, using settings similar to
“5 SDI2 Input Protect” on page 59 .
8 Genlock Source
This parameter selects the source of reference video used for genlock, either
automatically or explicitly. The same setting is applied to Video Processor 1 and Video
Processor 2
NOTE: HDMI can be used as a reference, but HDMI is not a valid reference source when the signal on
the HDMI input originates from a VESA-format computer DVI signal.
9 Output Frame
Rates
This parameter selects the HD video frame rate associated with the video standard.
NOTE: Changing the Frame Rates selection automatically selects a new value for “2 Output Format”
on page 64 . Each Frame Rates selection remembers its own Output Format settings.
10 FRC Enable
This parameter Enables or Disables the factory installed Frame Rate Converter (FRC)
option, if present. When present, the FRC PRES LED on the FS1-X front panel will be ON.
(Single Video signal)
1080p 50/60 setting, or
Auto Detect with ANC 1080p data, or
Auto Detect with no ANC data Dual Stream
SDI1 SDI1
SDI2 SDI2
Normal
SDI1 SDI1
SDI2 SDI2
SDI-3G Detect Setting
SDI2 Input Protect
Setting 1 Video Input
Setting Resulting Input to
Crosspoint Matrix
Reference (default)
Vid 1 Input
Free run Use the signal on the Ref connector as the genlock source.
Use the Vid1 input signal as the genlock source.
Free run mode (FS1-X syncs to its own timebase, not locked to an
external source).
59.94/23.98 (default)
50/25
24 Select 59.94/23.98 if your desired rate is either 59.94 or 23.98.
Select 50/25 if your desired rate is either 50 or 25 (PAL).
Select 24 if your desired rate is 24.
Enable (default)
Disable
Enables the FRC The FS1-X will operate in one channel mode,
using only Video Processor 1, and will activate the FRC when
required.
Disables the FRC. The FS1-X operates in two channel mode (using
both Video Processors 1 and 2), using add/drops for frame rate
conversion.
