2. Turn the SELECT knob to access menu Power Supply Alarm. The default alarm setting
is Normal.
3. Turn the ADJUST knob one click clockwise to change the setting to Suppress, which
turns off the alarm so that it will never come on.
4. Turn the SELECT knob clockwise again to access menu Vid1 Format Alarm.
5. Now change the Vid1 setting, using the ADJUST knob.
6. Continue by turning SELECT to access the Reference Alarm setting. Change the
settings using the ADJUST knob, if you wish.
Hidden Parameter
Menus: Video ProcAmp
These steps explain how to surf and change hidden parameter menus, such as the Video
ProcAmp settings.
1. Press the VIDEO PROC Menu Group button.
2. Turn the SELECT knob as necessary to display menu ProcAmp.
3. Turn the ADJUST knob to change the value setting from OFF (default) to ON.
4. Turn the SELECT knob clockwise to access menu ProcAmp Gain and set the Gain as
desired using the ADJUST knob.
5. Turn the SELECT knob one click clockwise to advance to the ProcAmp Black menu.
Turn ADJUST to set the black level.
6. Turn the SELECT knob clockwise again one click to advance to the ProcAmp Hue
menu. Turn ADJUST to set the hue.
Turn the SELECT knob to
scroll through parameter
menus.
SELECT ADJUST
5 Power Supply Alarm
Normal
Press the
CONFIG button
PS Alarm Menu
Current Setting
Labels (none)
Turn the ADJUST
knob to change
settings.
CONFIG
Turn SELECT knob to scroll
to menu 12.0 ProcAmp On/Off.
Use ADJUST to turn On. Turn
SELECT again to select/adjust
Gain, Black, Hue, and Sat.
SELECT ADJUST
12.0 ProcAmp
On
SDI 1 1080i59.94
Press the
VIDEO PROC button
Parameter Menu
Current Settings
Labels
Change setting
by turning the
ADJUST knob.
VIDEO
PROC
