FS1-X v1.1 www.aja.com 57
PRESET Menu Group
The PRESET Menu Group provides the means of saving, editing the names of, and loading
FS1-X presets. A preset is a set of all System, Video, Audio, and most Config parameters as
they were set at the time the preset was stored.
During recall, the display reads, Recalling until the recall is finished. On recall completion,
the displays shows the success or failure: Recalled, Failed, or Empty. A failed or empty
recall does not recall anything and leaves the FS1-X as it was. (Preset registers are empty
until you store something in them.)
During a store, the display reads Storing until the store is finished. On store completion,
the display shows Complete or Failed. A failed store does not store anything and leaves
the preset register as it was. To retry a failed store, turn SELECT to another preset number
and then back to the desired preset number.
1 Factory Preset
This parameter recalls a read-only Factory Preset.
1.1-1.40 Presets #1-
#40
These parameters let you recall, edit the name of, and store an FS1-X preset configuration
for the selected storage register. Forty storage registers are available.
Video with Audio
Routing
Presets can be used to coordinate audio and video routing. Store and name presets that
match the desired audio inputs to each desired video input, and use those presets to
select the video inputs, causing the configured audio to follow.
Caution!
When you recall a Preset Configuration, the recalled preset immediately replaces the
system’s existing configuration. All previous settings are lost unless you have
previously stored them in another preset configuration or an exported file.
Factory
Recall Recalls factory values for all System, Video, Audio, and most Config
parameters. Push ADJUST momentarily to perform (take) the
recall. The display reports “Loading” and “Complete” during the
recall. User preferences, network settings, and existing Presets
are not affected by recalling the Factory Preset.
Preset #1–#40
[Preset Name]
Recall
Edit Name
Store
Shows the currently selected preset register number. Turn SELECT
choose the desired register. Then turn ADJUST to choose Recall,
Edit Name, or Store for the selected register.
Shows the name of the selected preset register, which can be
edited.
Recalls that preset. Push ADJUST momentarily to perform (take)
the recall. The display reports “Loading” and “Complete” during
the recall.
Enables editing the name of the preset register. Push ADJUST to
enable editing (blinking character), use the SELECT and ADJUST
knobs to edit the name and then press ADJUST to save the
edited preset register name.
Stores the current set of all System, Video, Audio, and most Config
parameters to the selected preset register.
