FS1-X v1.1 www.aja.com 49
Output Status
This menu shows the video processor selected for each of the video outputs.
Power/Temp Alarm
This menu shows the power supply status of the FS1-X and the temperature status. If a
power supply is unplugged, the display top line indicates PS OFF or PS Error.
Caption Status
This menu shows what type of closed caption data is selected and whether closed
caption data is present on the selected video input.
FRC Status
This menu shows the status of the Frame Rate Converter. factory installed option. This
menu is hidden if the FRC option is not present.
MADI Status
This menu shows the status of the MADI input and output channels.
Display Description
SDI1 Selected Video Processor
SDI2 Selected Video Processor
Fiber1 Selected Video Processor
Fiber2 Selected Video Processor
HDMI Selected Video Processor
Analog Selected Video Processor
Selected Processor feeding the SDI 1 output.
Selected Processor feeding the SDI 2 output.
Selected Processor feeding the Fiber 1 output.
Selected Processor feeding the Fiber 2 output.
Selected Processor feeding the HDMI output.
Selected Processor feeding the Analog output.
Display Description
PS1 Alarm Status
PS2 Alarm Status
TmpAlarm Status
Displays the state of the PS1 power supply (OK or ERROR).
Displays the state of the PS 2 power supply (OK or ERROR).
Displays a temperature alarm if the FS1-X overheats.
Display Description
VID1CC Caption Type & Presence
ViD2CC Caption Type & Presence
Video Processor 1 selected caption type (SD/HD/Invalid)
and presence (Detected/Not detected/Pass through).
Video Processor 2 selected caption type (SD/HD/Invalid)
and presence (detected/not detected/Pass through).
Display Description
FRC Status
Mode Status Status
IN Source Format
OUT Format
Indicates if the FRC option is installed (Present or Absent).
Displays the current state of the FRC (Enabled or Disabled,
and Active or Bypass).
Displays the FRC input source and format.
Displays the FRC output signal format
Display Description
BNC In Mode Status
BNC Out Mode
FIB In
Mode Status
FIB Out Mode
Indicates the Mode (64 or 56 channels) and input signal
Status of the MADI BNC ports.
Indicates the Mode (64 or 56 channels) and input signal
Status of the MADI Fiber ports.
